OSPF简要设置：
network 0.0.0.0 255.255.255.255 area 0
Router#conf t
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)#router ospf ?
<1-65535> Process ID
Router(config)#router ospf 1//本地进程号
Router(config-router)#rou
Router(config-router)#router-id 2.2.2.2//区分路由器，不能重复
Router(config-router)#network 0.0.0.0 255.255.255.255 area 0
Router(config-router)#^Z
Router#
%SYS-5-CONFIG_I: Configured from console by consoleRouter#sh ip route
Codes: C - connected, S - static, I - IGRP, R - RIP, M - mobile, B - BGP
D - EIGRP, EX - EIGRP external, O - OSPF, IA - OSPF inter area
N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
E1 - OSPF external type 1, E2 - OSPF external type 2, E - EGP
i - IS-IS, L1 - IS-IS level-1, L2 - IS-IS level-2, ia - IS-IS inter area
* - candidate default, U - per-user static route, o - ODR
P - periodic downloaded static routeGateway of last resort is not set
C 6.0.0.0/8 is directly connected, FastEthernet0/0.1
C 7.0.0.0/8 is directly connected, FastEthernet0/0.2
O 8.0.0.0/8 [110/65] via 10.10.10.101, 00:00:29, Serial2/0
O 9.0.0.0/8 [110/65] via 10.10.10.101, 00:00:29, Serial2/0
C 10.0.0.0/8 is directly connected, Serial2/0
Router#
